ROL-LOC Mechanical Bracket


Model: QM-ROLO-SA Categories: , , Tags: ,
Share With:
  • Description

    A self-locking top clamp makes stowage a breeze.



    – Features a unique, self-locking, PVC-coated top clamp to securely lock SCBA cylinders without the need for straps or levers.

    – To secure the cylinder, place the cylinder valve into the footplate, then press the cylinder against the top clamp. The top clamp will roll up and out of the way to accept the cylinder, and then flip back to lock closed behind it. To release, simply pull on the release cord.

    – Fits most SCBAs with only minor adjustments.

    – Easy to retrofit into old or new seats. Works with most center pull releases.

    – Footplate Guide makes stowing the air pack an easy, no-look process.

    – NFPA compliant and third-party tested to exceed the 11G standard.

    Model Available:

    QM-ROLO-SA: Bracket with standard pull release

    Recommended: An optional Adjustable Footplate Kit allows for on-the-fly tweaks to the footplate height to accommodate for small variations in individual cylinders. See Model QM-AF-R.


    QM-AF-R – ROL-LOC Adjustable Footplate Kit
