Load & Lock SCBA Bracket

Documents

Documents

Share With:
  • Description

    The Load & Lock is our most economical SCBA bracket to meet the NFPA standard for use inside a crew cab.



    Features:

    – The simplistic design allows the bracket to work with many different makes and models of SCBA with minimal set up time.

    – Heavy-duty nylon strap firmly retains cylinder until released by pulling out on the release lanyard.

    – Backplate, footplate, and seats are thermoplastic-coated steel.

    – NFPA compliant and third party tested to exceed the 11G standard.



    Standard Models – Assembled:

    Note: These brackets are assembled before shipping for faster installation.

    30/45-Minute SCBA: Model ULLH

    60-Minute SCBA: Model ULLH-LF (plus Long Footplate, Model NEF, if using inside a crew cab)



    Ejector Spring Models – Assembled:

    Note: These brackets are assembled before shipping for faster installation. The Ejector Spring applies light force to the stowed cylinder and eases cylinder release when strap is removed.

    30/45-Minute SCBA: Model ULLH-ES

    60-Minute SCBA: Model ULLH-ES-LF (plus Long Footplate, Model NEF, if using inside a crew cab)



    Standard Models – Unassembled:

    Note: These brackets ship unassembled. A slightly more economical option.

    30/45-Minute SCBA: Model KD-ULLH

    60-Minute SCBA: Model KD-ULLH-LF (plus Long Footplate, Model NEF, if using inside a crew cab)



    Ejector Spring Models – Unassembled:

    Note: These brackets ship unassembled. A slightly more economical option. The Ejector Spring applies light force to the stowed cylinder and eases cylinder release when strap is removed.

    30/45-Minute SCBA: Model KD-ULLH-ES

    60-Minute SCBA: Model KD-ULLH-ES-LF (plus Long Footplate, Model NEF, if using inside a crew cab)



    Release Assist Models – Unassembled:

    Note: These brackets ship unassembled. A slightly more economical option. The Release Assist allows the release cord to be pulled up or down in addition to straight out.

    30/45-Minute SCBA: Model KD-ULLH/LLS/RA

    60-Minute SCBA: Model KD-ULLH-LF and Model LLS/RA (plus Long Footplate, Model NEF, if using inside a crew cab)
